We keep all engine parts for the Bobcat Skidsteer 751 up to 1999 fitted with the Peugeot engine. We keep gaskets, belts, water pumps, oil pumps, cams, cam caps, seals, valves, guides & much more.

Tightening Torques for XUD9 1905cc Diesel Engine


Part Nm Kgm ft-lb
Connecting rod end caps 50 5 37
Camshaft bearing caps 17.5 1.8 13
Camshaft gear 40 4 30
Coolant pump 15 1.5 11
* Crankshaft pulley 40 + 60° 4 + 60° 30 + 60°
Cylinder head bolts  pre-tightening
 * tightening
30
70 +120°
3
7 + 120°
22
52 + 120°
Cylinder head cover 10 1 7
Flywheel 50 5 36
Glow plugs 22 2.2 16
Injector pump gear 57 4.7 33
Injector into Cylinder Head 90 9 66
Main bearing caps 70 7 52
Oil pump 20 2 15
Oil seal carrier, timing gear end 15 1.5 11
Sump to block 20 2 15
Timing belt tensioner 15 1.5 11
Water drain plug 25 2.5 18
Oil drain plug 37 3.7 27
Tension roller pin nut 17 1.7 12
Manifold screws 22 2.2 16
Alternator bracket 17 1.7 12

* NOTE: 40 + 60° is tighten to 40 Nm then an additional 60° (60 degrees) of rotation (one flat of bolt head)
